Qinsy 9.8.3 - Known Issues

The QPS team is continuously improving Qinsy to implement new functionality and documentation.
Unfortunately, there are a number of known issues in our software release.

These software issues will be solved in future maintenance releases.

Licensing

With this release, there is a new License Manager version 1.10.2.

The new License Manager fixes the issue where an error would appear in the dialog “Failed to Activate License” with the message “There are network adapters on the system that are disabled, please enable them and try again.” when trying to activate the softlock license. Older versions of Qimera may still experience this issue.

If you activate the license in Qinsy 9.8.0 and then open an earlier version, the softlock license may be lost.
The fix is to manually copy the DLLs into that older version:

Long running known issues

Click to expand...

Displays - Navigation - CAD - Design Models.

Converting a design file into a background file will not show lines when the start and end point of a line are outside the view. (Viewing Panel)

Recommendation
Do not convert design files into background files. If lines from a design are needed in the Navigation Display, then create a dedicated background file.

Displays - Navigation - CAD Survey Manager

The QPS team encountered a memory problem with CAD files which contain many complex blocks.

Recommendation
Do not use CAD files which contain many complex blocks. This bug will be solved in a future maintenance release.
Make sure you explode the Blocks in CAD before you try to import these files into survey software.

Displays - Navigation - ENC Survey Manager

Both the Survey Manager and Navigation Display are not Per monitor DPI aware.
With two monitors, each with different display scales, the scale on the secondary monitor will not be correct.
This also affects the way the ENCs are drawn.

Recommendation
Please vote on: FQI-605

Survey Manager - Plan View - ENC

ENCs produced by Rijkswaterstaat for the Dutch province of Zeeland and ENCs produced by the Netherlands Hydrographic office cannot be displayed simultaneously due to the different usage levels and compilation scales of both producers.

For more information and updates: https://vaarweginformatie.nl/frp/main/#/page/infra_enc

Survey Manager - Static Grid - Import Geoid Model

Since Qinsy 9.5.0 it is possible again to import most Geoid models into a Static Grid.
The only Geoid models that cannot be imported yet are the ones that cross the dateline (+180° East/West).

Please let us know if you do need to import such a model.
