Qimera 2.2.2 Release

18 June 2020

We're pleased to present Qimera version 2.2.2, a maintenance release addressing small issues. Read below for details.

Vote

Click on the icon above and vote on or create a Feedback issue!

Highlights

• Interpolation is now possible with CUBE depth surfaces, all other CUBE related fields like hypothesis count are left at zero.
• License Manager will now display disabled products to allow for proper de-activation in the event that the user would like to re-activate.

Bugs

• Tools and Editors

  • Measure Tool - Crash when enabling view of Dynamic Surface after running measuring tool
  • Measure Tool - Crash when doing a measurement for the second time
  • Profile - Red dot indicator stops when outside main dynamic surface
  • 3D Editor - Sometimes reporting no soundings loaded in selected area
  • Slice Editor - Removed maximum cap on vertical exaggeration control (50x)
  • Slice Editor - Fixed crash when warning that maximum point count is reached
  • Swath Editor - Pick/add soundings with dual swath KMALL
  • Swath Editor - Fixed crash that occured with Qinsy .db files containing multiple objects

  • TU Delft Sound Speed Inversion - Disallow algorithm from working on laser data

  • TU Delft Sound Speed Inversion - Fixed problem where some data rejected after running inversion

• Patch Test Tool
  • Tools and Docks - Patch Test Tool - Lines don't clear after deselection
  • Patch test - Tickbox to apply/unapply offset was not working
• Surfaces
  • Appending to grid - Surface was not expanding correctly when data was appended outside of grid bounds
  • Duplicating a Surface - Newly duplicated surface was including files that were removed from the original surface
  • Fixed crash when building CUBE surface
  • Surface Difference - Fixed use of area selection which was applied inconsistently depending on the order that surfaces were selected
  • Export - Fixed problem where Export to surface was not respecting the user's choice of selected layer
  • CUBE filter soundings - Option to Clear Rejected Flag was not working correctly
  • CUBE filter for soundings - Dialog was defaulting to "Selection" when there is no selection made
• Other

  • Overview Widget - Improve consistency in color map application between Scene and Surface Edit Overview after application of large z-offet to a Dynamic Surface
  • Fixed Time-Series Editor crash that occurred after selecting a particular file in the project overview
  • qimera-command now works with relative paths given on the command line
  • Project Sources - Ctrl+A was selecting files from multiple types
  • Project name was truncating in the title bar if it contained any periods in the project name
  • Color Maps - Fixed importer for GMT .cpt color map files
  • Background ENC chart SD showing up in 'Drape Imagery onto Surface' dialog

Feedback Project

For more information, see our Voting System Policy and Using the feedback project.

The Feedback Project helps us to continue improving our software products. Vote on or implement feedback and participate in the process by tracking, watching and commenting on issues!

Please click on the Vote button to the right to go to the Qimera Feedback Project and implement or find the item you want to vote for.
